Hi-Res audio with wired input on Sonos Ace

Trying to understand if it’s possible to play hi-res audio on Sonos Ace. Seems like bluetooth is a no-go, but I was hoping that the USB-C to USB-C connectivity would support it. However when I connect them to my Mac and open Audio Midi Setup, the Sonos Ace audio device only reports 16bit and 48kHz, and I can’t select any other option. Not sure if there is any limitation on MacOS here, and if it’s possible to use higher sampling or depth on other devices. Anyone had any success with this?

The 3,5mm to USB-C adapter it’s a different mystery. From what I can understand this is a ADC adapter, and not an analoge passthrough cable using USB-C’s Audio Accessory Mode. So even if I use a DAC from the computer that supports hi-res, the signal is anyway converted back to digital using the adapter cable, and then probably ending up using the same DAC that is used for USB-C to USB-C. There is so many conversions going on in this signal path it feels like a bit of a stretch to even call it lossless (as Sonos is stating).

Am I getting this all wrong?

This topic has been closed for further comments. You can use the search bar to find a similar topic, or create a new one by clicking Create Topic at the top of the page.
HiFi Oasis
Lyricist III
Jul 31, 2024 3:57 PM UTC

I was curious about this during my review of the Ace, so I reached out to my contact and they confirmed that the 16-bit/48kHz limitation is also applied to the 3.5mm connection. This would make sense since the connection needs to go through the onboard DAC of the Ace regardless of the cable used.

58 replies

press250
Prodigy III
Jul 31, 2024 6:11 PM UTC

Hi @HiFi Oasis, terminology correction to your thesis: your suggestion is that an analog signal goes through an analog-to-digital converter (ADC), then through EQ in the digital domain, and finally through a digital-to-analog converter (DAC) ...

        analog input > ADC > digital EQ > DAC

I cannot say if that is what happens in the Ace headphones, tho’ I know there are audio components that employ such a signal path.

Translate
Ken_Griffiths
Jul 31, 2024 11:14 PM UTC

This is what I’m seeing… I played the same Neil Young ‘Rust’ album tracks using Amazon Music UHD - the audio quality is shown as 24/192 on the AM UHD service (iPad Pro). I output that audio to the UGreen DAC and in-turn ran an analog audio cable into a Sonos Five line-in port and that gave me this display in the App…

I think 24/48 audio is what a Sonos S2 product is capable of these days and the older S1 system can apparently handle upto 16/44 audio IIRC. (I’m sure someone will correct me if I have these things wrong). I don’t have an S1 product with a line-in to test with the DAC to see if the output changes to 16/44.

Anyhow, if I leave the UGreen DAC connected to the iPad and remove the line-in analog cable linked to the Five and simply replace it with the 3.5mm to USB-C (ADC) cable (supplied with the Headphones) and connect it to the Ace and restart the same track, I then see this….

When I saw this, it led/leads me to believe that the Ace supports 24/192 audio… but if I ditch the UGreen DAC altogether and just do a straight through USB-C to USB-C link instead between the iPad & Ace, I see an output of 24/48 audio - so I think at the very least the Ace supports 24/48 audio quality - I’m just not sure why I’m seeing 24/192 when I use the UGreen DAC.

Someone might have to clear the mist for me, but at no point in my own tests, have I seen 16 bit audio when playing a 24 bit audio track. Even the lighting to 3.5mm iPhone adapter I also mentioned in my earlier post gave me a display showing 24/48 audio on the Ace when playing the ‘Rust’ album tracks.

I can only speak as I find, but I’ll be surprised if a wired Ace is just capable of playing upto 16/44 audio, rather than UHD 24/48, or higher, but maybe someone will go onto show evidence to prove me wrong. I should add that I am not in anyway obsessed by these things, labels/badges in Apps… and happy with CD Quality 16/44 audio anyway. I’m just curious to know the actual answer of what the Ace can/will support.



Translate
press250
Prodigy III
Jul 31, 2024 11:33 PM UTC

Hi @Ken_Griffiths, this discussion has kinda’ mixed-and-matched the two different ways to connect to Ace in a wired manner …

  • Digital. This is what we normally think about when connecting over USB, a purely digital signal path from phone/tablet/computer to headphones. The digital-to-analog conversion is performed by the DAC inside Ace, and that DAC appears to be capable of 24bit/48kHz. Which is quite stellar audio quality my any measure!
  • Analog. This is old school 3.5mm territory, an analog signal path from device to headphones. The digital-to-analog conversion is performed by a DAC inside the phone/tablet/computer … or by your UGreen DAC that is capable of 24bit/192kHz. In this case, it doesn’t make sense to talk about the Ace bitdepth/bitrate because it receives an analog signal.

It’s a fair bet that the DAC inside Ace is capable of 24bit/48kHz, based on everything you’ve shown. And your UGreen DAC may very well sound different, not so much because of the ‘better’ specs but because it has its own sonic characteristics.

Translate
Ken_Griffiths
Aug 1, 2024 12:02 AM UTC

Hi @Ken_Griffiths, this discussion has kinda’ mixed-and-matched the two different ways to connect to Ace in a wired manner …

  • Digital. This is what we normally think about when connecting over USB, a purely digital signal path from phone/tablet/computer to headphones. The digital-to-analog conversion is performed by the DAC inside Ace, and that DAC appears to be capable of 24bit/48kHz. Which is quite stellar audio quality my any measure!
  • Analog. This is old school 3.5mm territory, an analog signal path from device to headphones. The digital-to-analog conversion is performed by a DAC inside the phone/tablet/computer … or by your UGreen DAC that is capable of 24bit/192kHz. In this case, it doesn’t make sense to talk about the Ace bitdepth/bitrate because it receives an analog signal.

It’s a fair bet that the DAC inside Ace is capable of 24bit/48kHz, based on everything you’ve shown. And your UGreen DAC may very well sound different, not so much because of the ‘better’ specs but because it has its own sonic characteristics.

Yes, makes sense, but just to say I don’t think the Ace Headset sounds any better with the UGreen adapter - it just sounds the same to me - Anything over and above 16/44 CD quality is lost on me as I’m just from the planet Earth. 😀

The one point I just want to raise here (causing myself some confusion) is when using the UGreen DAC, the cable from that to the Ace is 3.5mm analog to USB-C - I wonder why the Amazon Music App displays 24/192 in that instance on the Ace, but 24/48 for the line-in on the ‘Five’, when clearly the analog signal there (for each Sonos device) is a voltage wave form with no 0’s/1’s and therefore it’s not got a digital bitrate, or sample rate, but the App is able to distinguish that the line-in on the Five is capable of 24/48, but shows the Ace as capable of 24/192 - that’s where the mist is in my own case? I hope that makes sense.

Anyhow, I too think the Ace is capable of handling 24/48 audio (currently) as the straight-through digital USB-C to USB-C link is suggesting that - it’s why I included it in my post earlier. I am still wondering though why I’m seeing 24/192 for the Ace with that DAC and it will keep niggling me until I see something that might help clear the mist.

Translate
Ken_Griffiths
Aug 1, 2024 12:42 AM UTC

Maybe it’s a case that the Ace’s own DAC is itself actually capable of 24/192 audio quality and is somehow reporting that fact, but it’s full potential has not yet been unleashed and Sonos have currently restricted it to 24/48 for the time being. That’s what my own thoughts are, but it’s just ‘blue sky’ thinking with nothing really tangible in support of the idea.

Translate
Contributor I
Aug 2, 2024 5:36 AM UTC

Hi @Ken_Griffiths, this discussion has kinda’ mixed-and-matched the two different ways to connect to Ace in a wired manner …

  • Digital. This is what we normally think about when connecting over USB, a purely digital signal path from phone/tablet/computer to headphones. The digital-to-analog conversion is performed by the DAC inside Ace, and that DAC appears to be capable of 24bit/48kHz. Which is quite stellar audio quality my any measure!
  • Analog. This is old school 3.5mm territory, an analog signal path from device to headphones. The digital-to-analog conversion is performed by a DAC inside the phone/tablet/computer … or by your UGreen DAC that is capable of 24bit/192kHz. In this case, it doesn’t make sense to talk about the Ace bitdepth/bitrate because it receives an analog signal.

It’s a fair bet that the DAC inside Ace is capable of 24bit/48kHz, based on everything you’ve shown. And your UGreen DAC may very well sound different, not so much because of the ‘better’ specs but because it has its own sonic characteristics.

Yes, makes sense, but just to say I don’t think the Ace Headset sounds any better with the UGreen adapter - it just sounds the same to me - Anything over and above 16/44 CD quality is lost on me as I’m just from the planet Earth. 😀

The one point I just want to raise here (causing myself some confusion) is when using the UGreen DAC, the cable from that to the Ace is 3.5mm analog to USB-C - I wonder why the Amazon Music App displays 24/192 in that instance on the Ace, but 24/48 for the line-in on the ‘Five’, when clearly the analog signal there (for each Sonos device) is a voltage wave form with no 0’s/1’s and therefore it’s not got a digital bitrate, or sample rate, but the App is able to distinguish that the line-in on the Five is capable of 24/48, but shows the Ace as capable of 24/192 - that’s where the mist is in my own case? I hope that makes sense.

Anyhow, I too think the Ace is capable of handling 24/48 audio (currently) as the straight-through digital USB-C to USB-C link is suggesting that - it’s why I included it in my post earlier. I am still wondering though why I’m seeing 24/192 for the Ace with that DAC and it will keep niggling me until I see something that might help clear the mist.



I was also hoping it would be capable of 24/48 (which seems to be the what the internal DAC of other Sonos products support), that’s why I was a bit surprised when I only see 16/48 on my Mac when using usb-c to usb-c (which correlates to what @HiFi Oasis also has found). But based on our screenshots, you were able to get 24/48 with usb-c to usb-c using iPad and Amazon Music?

I did test the 3.5 to usb-c cable included with Ace on my Era 300, and it works. Since the Era does require a digital input (afaik), it shows that this cable includes a ADC and there is a ADC/DAC conversion when using analog from source as well.





Translate
Avid Contributor I
Aug 13, 2024 12:23 PM UTC

Hi

from mi MacBook Air M1 ace with USB C in midi Options I see 24 bit 48hz only one option.

Andrea.



Translate
Ken_Griffiths
Aug 13, 2024 12:26 PM UTC

Hi

from mi MacBook Air M1 ace with USB C in midi Options I see 24 bit 48hz only one option.

Andrea.

I think that’s pretty much the consensus that the Ace supports up-to 24/48 lossless HiRes audio over a wired connection.

Translate
Contributor I
Aug 13, 2024 12:46 PM UTC

Hi

from mi MacBook Air M1 ace with USB C in midi Options I see 24 bit 48hz only one option.

Andrea.



Is this for Input or for Output in the MIDI Options? On input (mic) I also see 1ch 24bit, but for output I only get 2ch 16bit

Translate
sigh
Prodigy II
Aug 13, 2024 1:20 PM UTC

Anyhow, if I leave the UGreen DAC connected to the iPad and remove the line-in analog cable linked to the Five and simply replace it with the 3.5mm to USB-C (ADC) cable (supplied with the Headphones) and connect it to the Ace and restart the same track, I then see this….

When I saw this, it led/leads me to believe that the Ace supports 24/192 audio… but if I ditch the UGreen DAC altogether and just do a straight through USB-C to USB-C link instead between the iPad & Ace, I see an output of 24/48 audio - so I think at the very least the Ace supports 24/48 audio quality - I’m just not sure why I’m seeing 24/192 when I use the UGreen DAC.

Someone might have to clear the mist for me, but at no point in my own tests, have I seen 16 bit audio when playing a 24 bit audio track. Even the lighting to 3.5mm iPhone adapter I also mentioned in my earlier post gave me a display showing 24/48 audio on the Ace when playing the ‘Rust’ album tracks.

I can only speak as I find, but I’ll be surprised if a wired Ace is just capable of playing upto 16/44 audio, rather than UHD 24/48, or higher, but maybe someone will go onto show evidence to prove me wrong. I should add that I am not in anyway obsessed by these things, labels/badges in Apps… and happy with CD Quality 16/44 audio anyway. I’m just curious to know the actual answer of what the Ace can/will support.



If it helps clear the mist, The above isn’t showing anything about the adc rates after the analogue cable, you are seeing the ugreen adapter input value. The ugreen adapter has no way to display what is happening inside the Ace or the ace 3.5mm to usb cable over the analogue connection.

If you have a 32bit/384Khz source going into the ugreen that output would list 32 bit/384 kHz.

What it is showing isn’t the full signal path which is

Source 24/192 — digital — iPad Pro 24/192 — digital — ugreen input 24/192 — ugreen DAC output (analogue) — 3.5mm analogue — ace cable ADC — ace

What it does show is nothing has changed the bit size and sample rate (24/192) from the source to the ugreen adapter input. It isn’t showing you what happens after the ugreen converts it to analogue. So what the adc in the cable or the ace internal values are.
